AUDIO SPECIFICATIONS

FREQUENCY RANGE
45 - 20k Hz

MONO / STEREO
Stereo

MAXIMUM SOUND PRESSURE LEVEL
RMS : 118 dB SPL @ 1m
Peak : 121 dB SPL @ 1m

CABINET PRINCIPLE
Bass Reflex

POWER AMPLIFIERS
150W RMS / 450W Peak, Class D Amplifier

SPEAKERS
2 x 1 inch Compression Tweeter with Custom Angled Horn
2 x 6.5 inch Custom Designed Woofer
2 x Reflex Port

TOTAL IMPEDANCE
4 ohms

CONTROLS AND CONNECTIVITY

FRONT PANEL CONTROLS
Power Button
Channel 1 Eight Programmable Preset Selector
Channel 1 Amp Controls (Gain, Bass, Mid, Treble, Master
Channel 1 Volume
Music Channel Volume

REAR PANEL CONTROLS
Pair Button
Channel 2 Eight Programmable Preset Selector
Channel 2 Volume
Channel 3&4 Volume
Center-click Master Controls (Low, Mid, High, Volume)

COMPUTATIONAL AUDIO
Sonic IQ Computational Audio

• Dedicated Computational Audio Chip
• Dynamic Range Compression
• Bass & Vocal Enhancement
• Stereo Widening
• Auto EQ

ONBOARD EFFECTS
Channel 1:
33 Amp Models (For electric guitar, acoustic guitar, bass)
43 Effects (Noise Gate, Compressor, Distortion, Modulation/EQ, Delay, Reverb)
Choose up to 3 pre-amp effects, 3 post amp effects, and 1 amp model for each preset

Channel 2:
3 Amp Models (For vocal, bass & acoustic guitar)
50 Effects (Noise Gate, Compressor, Distortion, Modulation/EQ, Delay, Reverb)
Choose up to 1 pre-amp effects, 2 post amp effects, and 1 amp model for each preset

WIRED CONNECTIVITY
1/4" Instrument Input x 3
XLR / 1/4" Combo Input x 1
1/8" Headphone Output x 1
1/4" Line Output x 2 (L/Mono & R)
Din 5pin MIDI Jack x 2 (In & Out)

WIRELESS CONNECTIVITY
Bluetooth 5.0
USB AUDIO
USB Interface for Recording
2 In x 2 Out
Sample Rate: 48kHz
Bit Depth: 24
Compatible with MacOS and Windows



PHYSICAL UNIT

DIMENSIONS
Spark LIVE:
L 464 x W 250.6 x H 306 mm
(L 18.26 x W 9.86 x H 12.04 inch)
Spark Battery (sold separately):
L 86 x W 74 x H 48.7 mm
(L3.38 x W2.91 x H1.91 inch)

WEIGHT
Spark LIVE:
12 kg
26.45 lb
Spark Battery (sold separately):
480g
1.05 lb

GRILLE CLOTH
Custom Black/Brown

SOFTWARE
MOBILE APPS
Spark App for iOS and Android (included)

Spark App Core Features
Smart Jam - 4 Drummers Included
Auto Chords
50,000+ Tones On ToneCloud®
Video Recording
Tuner
Mixer View (Spark LIVE exclusive)

INCLUDED IN THE BOX

BOX CONTENTS
Spark LIVE Amplifier
USB A to C Cable
Power Cord (2M)
Quick Start Guide
Safety Instructions Card

POWER

MAIN INPUT POWER
AC 100-240V

USB-C POWER OUTPUT (Charging Port)
DC 5V/1.5A

BATTERY TYPE (Spark Battery)
Detachable 6,000 mAh rechargeable lithium-ion battery
(Spark Battery sold separately.)


PLAY TIME
Up to 8 hours (on mid volume)

CHARGING TIME
3 Hours
